Why Choose the ILME BC1123Q2 Cover for 2 Sockets?
The ILME BC1123Q2, also identified as BC 1123 Q2, is a purpose-designed cover for two straight flush-mounting industrial socket outlets within the ILME BK distribution system. Designed for compatible 16 A and 32 A socket configurations, it provides two openings for sockets with an 80 × 80 mm flange, allowing compact and organised power distribution assemblies to be created.
The BC1123Q2 has a cover centre distance of 114 × 228 mm and forms part of ILME's modular BK system for industrial socket-outlet combinations. BK system components use self-extinguishing glass-fibre-reinforced polyester construction in RAL 7035 grey, with stainless-steel exterior metal parts and oil-resistant anti-ageing rubber gaskets for dependable performance in demanding installations.
When correctly assembled as part of a compatible ILME BK system, the enclosure system can provide protection up to IP66/IP67. The BC1123Q2 is therefore well suited to factories, machinery, workshops and industrial power distribution applications where two flush-mounted 16 A or 32 A socket outlets need to be integrated into a compact, robust enclosure system.
Key Advantages
- Purpose-designed cover for two straight flush-mounting socket outlets.
- Suitable for compatible industrial sockets with an 80 × 80 mm flange.
- Designed for 16 A and 32 A socket-outlet applications.
- Part of the modular ILME BK distribution system.
- 114 × 228 mm cover centre distance for integration with compatible BK components.
- Glass-fibre-reinforced polyester BK system construction provides excellent mechanical durability.
- Self-extinguishing material supports professional industrial electrical installations.
- RAL 7035 grey finish integrates neatly with compatible ILME distribution equipment.
Key Features
- ILME BK Series distribution system accessory.
- Cover with openings for two flush-mounting socket outlets.
- Designed for straight socket outlets.
- Suitable for sockets with 80 × 80 mm mounting flanges.
- Suitable for compatible 16 A and 32 A socket applications.
- 114 × 228 mm cover centre distance.
- Self-extinguishing glass-fibre-reinforced polyester BK system construction.
- Grey RAL 7035 finish.
- Designed for compact industrial distribution assemblies.
- Compatible with the ILME BK modular enclosure concept.
- Approximate weight of 310 g.
- Manufactured in Italy.
Flexible Industrial Socket Distribution with the ILME BK System
The ILME BK distribution system provides a modular approach to creating compact industrial power distribution assemblies. Covers such as the BC1123Q2 allow straight flush-mounting socket outlets to be incorporated into compatible boxes while maintaining a clean and organised installation. The two-opening arrangement makes efficient use of available enclosure space where multiple socket outlets are required.
The BC1123Q2 is specifically configured for two sockets with 80 × 80 mm flanges, making it a practical choice for compatible 16 A and 32 A industrial socket installations. Combined with the appropriate ILME BK system components and correctly assembled, it supports robust power distribution solutions for demanding industrial environments.
Typical Applications
- Industrial 16 A and 32 A socket-outlet assemblies.
- ILME BK modular distribution systems.
- Factory and production-line power distribution.
- Machine building and automation equipment.
- Industrial workshops and maintenance facilities.
- Manufacturing and processing installations.
- Compact dual-socket power distribution points.
- Industrial electrical enclosure construction and refurbishment.
