Why Choose the Ilme TM1125P16 Cover for 2 Socket Outlets?
The Ilme TM1125P16 is a durable single-module thermoplastic cover with two housings for 16 A inclined flush-mounting socket outlets. Part of the Ilme TM distribution system, it is designed to accommodate two compatible socket outlets with 64 × 82 mm flanges, providing a practical solution for industrial power distribution assemblies.
Manufactured from insulating, self-extinguishing thermoplastic material, the TM1125P16 is designed for reliable service in industrial installations. The cover is finished in RAL 7012 grey and incorporates captive stainless-steel cover fixing screws, with stainless-steel screws also provided for securing the socket outlets.
The cover has an overall format of approximately 114 × 255 mm with a depth of 28 mm. When mounted on compatible TM boxes and used with suitable Ilme PEW socket outlets, the assembly can meet IP67 protection requirements, making it suitable for demanding industrial power distribution applications.
Key Advantages
- Designed for two 16 A inclined flush-mounting socket outlets.
- Compatible with socket outlets featuring a 64 × 82 mm flange.
- Strong self-extinguishing insulating thermoplastic construction.
- RAL 7012 grey finish for integration with Ilme TM distribution equipment.
- Captive stainless-steel fixing screws simplify installation and maintenance.
- Supports IP67 protection when correctly installed with compatible TM boxes and PEW socket outlets.
Key Features
- Ilme TM distribution system accessory.
- Single-module cover with 2 socket housings.
- Designed for 16 A inclined flush-mounting sockets.
- Suitable for 64 × 82 mm flange socket outlets.
- Type PI fixing arrangement with 52 × 60 mm fixing-hole centres.
- Also suitable for compatible GW 27042 domestic insert carriers.
- Insulating self-extinguishing thermoplastic construction.
- Captive cover fixing screws in stainless steel.
- Socket-outlet fixing screws in stainless steel included.
Practical Socket Mounting for Industrial Power Distribution
The Ilme TM distribution system provides a modular approach to assembling industrial socket-outlet and power distribution equipment. The TM1125P16 creates two dedicated mounting positions for compatible 16 A inclined flush-mounting socket outlets, allowing a compact power distribution arrangement to be built using compatible TM boxes and accessories.
Its insulating thermoplastic construction, stainless-steel fasteners and compatibility with high-protection socket assemblies make the TM1125P16 well suited to workshops, manufacturing equipment and industrial distribution installations where reliable access to electrical power is required.
Typical Applications
- Industrial power distribution boxes.
- Manufacturing and production facilities.
- Machinery power distribution points.
- Workshop electrical installations.
- Automation and control equipment.
- Modular industrial socket-outlet assemblies.
