Why Choose the ILME MZFO15L20 High Construction Hood?
The ILME MZFO15L20 is a robust High Construction heavy-duty connector hood designed for detachable multipole electrical connections in industrial machinery, automation and control equipment. Featuring the compact ILME size 49.16 interface, it provides a protective cable-side enclosure for compatible connector inserts and their terminations.
The MZFO15L20 incorporates two locking pegs for secure engagement with a compatible lever-equipped mating housing. Its M20 side cable entry provides a practical horizontal cable approach, making the hood especially useful where installation space above the connector is restricted or cabling needs to follow the machine surface.
Its High Construction profile provides additional internal space for cable routing and termination compared with lower-profile enclosure designs. Combined with its durable metal construction, compact size and side-entry arrangement, the MZFO15L20 is a practical enclosure for industrial power, control and signal connector assemblies.
Key Advantages
- Robust High Construction connector hood for industrial multipole connections.
- Size 49.16 interface for compatible ILME connector inserts.
- M20 side cable entry supports convenient horizontal cable routing.
- Two locking pegs provide secure engagement with a compatible lever housing.
- High Construction profile provides additional internal wiring space.
- Durable enclosure design for machinery, automation and industrial electrical equipment.
Key Features
- ILME heavy-duty connector enclosure.
- High Construction hood configuration.
- Size 49.16 connector interface.
- M20 side cable entry.
- Single cable-entry configuration.
- Equipped with two locking pegs.
- Designed to mate with a compatible lever-equipped housing.
- Metal enclosure construction for industrial use.
- Protects compatible multipole inserts and cable terminations.
- Suitable for power, control and signal connector systems.
High Construction Side-Entry Connectivity
Heavy-duty multipole connectors allow several electrical circuits to be combined within one detachable interface, helping simplify machine installation, maintenance and replacement. The ILME MZFO15L20 forms the cable-side enclosure of a compatible connector assembly, protecting the insert and termination area while providing additional internal space through its High Construction profile.
The M20 side-entry arrangement allows cabling to approach horizontally rather than directly above the connector. Its two locking pegs engage with the locking mechanism of a compatible mating housing, creating a practical connection arrangement for machinery and industrial equipment where compact dimensions and dependable mechanical coupling are important.
Typical Applications
- Industrial machinery and machine building.
- Factory automation and production equipment.
- Packaging and processing machinery.
- Material handling and conveyor systems.
- Control and instrumentation equipment.
- Industrial power, control and signal connections.
