Ilme PEW1694SV is a 16 A, 200–250 V AC, 4-pole 3P + E industrial mobile plug with IP67 protection, screw terminals and a 9 h protective earth position for reliable industrial power connections.
SKU:PEW1694SVAlt SKU:PEW 1694 SVMPN:PEW1694SV
Price
List Price£11.79ex VAT
Your Price (ex VAT)
£11.79
Manufacturer Lead TimePlease contact us for a delivery time before you order
Get the best trade pricesTrade exclusive
Create a trade account to unlock exclusive pricing, special offers and more.
Why Choose the Ilme PEW1694SV 16 A 230 V 4 Pole IP67 Plug?
The Ilme PEW1694SV is a robust 16 A industrial mobile plug designed for reliable power connections in demanding industrial, commercial and automation environments. Manufactured as part of Ilme’s industrial plug and socket range, this 4-pole connector provides a secure solution for three-phase equipment requiring dependable electrical performance and environmental protection.
Designed in accordance with EN 60309-1 and EN 60309-2, the PEW1694SV features a durable insulating thermoplastic enclosure, screw-terminal connections and a cable-gland entry for secure cable termination. Its IP67 construction helps protect the electrical connection against dust and temporary immersion in water when correctly assembled and connected to a compatible mating device.
With a rated current of 16 A and an operating voltage range of 200–250 V AC at 50 / 60 Hz, the PEW1694SV uses a 3P + E, 4-pole configuration with the protective earth contact positioned at 9 h. The blue voltage identification and rugged straight plug design make it suitable for industrial machinery, temporary power systems, factory equipment and other professional electrical installations.
Key Advantages
Professional 16 A industrial mobile plug for demanding electrical installations.
200–250 V AC, 50 / 60 Hz rating for compatible industrial power systems.
4-pole 3P + E configuration with protective earth contact at 9 h.
IP67 protection for reliable use in challenging industrial environments.
Screw-terminal connection provides secure and serviceable cable termination.
Key Features
Ilme PEW industrial plug series.
16 A rated current.
200–250 V AC operating voltage.
4 poles: 3P + E.
9 h protective earth position.
50 / 60 Hz operating frequency.
IP67 degree of protection.
Blue voltage identification in accordance with industrial connector conventions.
Screw-terminal electrical connections with retained screws.
Straight cable-entry design with cable gland.
Reliable Industrial Power Connections
Industrial plugs such as the Ilme PEW1694SV provide a secure and standardised method of connecting machinery and electrical equipment to suitable power supplies. The keyed pole arrangement and defined protective earth position help prevent connection to incompatible industrial socket configurations.
The PEW series is engineered for professional electrical installations where mechanical durability and environmental protection are important. Its thermoplastic construction, gasketed locking arrangement, screw terminals and IP67 protection make the PEW1694SV particularly suitable for factories, workshops, machinery installations and other environments where dependable power connectivity is required.
Typical Applications
Industrial machinery and production equipment.
Factory and workshop electrical installations.
Automation and machine-building systems.
Portable and temporary industrial power distribution.
Processing and manufacturing equipment.
Commercial and industrial electrical installations requiring IP67 connectivity.
Technical Specifications
Tick the specs you need, then view products that match.
Clock Position (h)
9 h
Current
16 A
Voltage
200–250 V AC
Mounting Type
Portable / in-line
Connection
Screw
Device Type
Industrial Plug / Socket
Housing Material
Thermoplastic
Product Series
ILME PEW
Contacts
4 poles
Manufacturer
Ilme
Series
PEW Industrial Plugs
Model
PEW1694SV
Alternative part number
PEW 1694 SV
Product type
Industrial mobile male plug
Rated current
16 A
Rated voltage
200–250 V AC
Nominal voltage
230 V AC
Number of poles
4
Pole configuration
3P + E
Protective earth position
9 h
Frequency
50 / 60 Hz
Protection rating
IP67
Connection type
Screw terminals
Cable entry
Cable gland
Plug direction
Straight
Material
Insulating self-extinguishing thermoplastic
Voltage identification colour
Blue
Enclosure colour
RAL 7035 grey
Reference standards
EN 60309-1 and EN 60309-2
Barcode / EAN
8015747073882
Poles
4-pole
IP Rating
IP67
Frequently Asked Questions
What is the Ilme PEW1694SV used for?
The PEW1694SV is a 16 A industrial mobile plug used to connect compatible three-phase machinery and electrical equipment to industrial power systems.
What voltage is the PEW1694SV rated for?
The plug is designed for 200–250 V AC at 50 / 60 Hz and is commonly specified for nominal 230 V industrial applications.
How many poles does the PEW1694SV have?
The PEW1694SV is a 4-pole connector with a 3P + E configuration, providing three phase contacts and one protective earth contact.
What is the IP rating of the Ilme PEW1694SV?
The PEW1694SV has an IP67 protection rating, providing protection against dust and temporary immersion in water when correctly assembled and connected to a suitable mating device.
What type of terminals does the PEW1694SV use?
The plug uses screw-terminal connections with a cable-gland entry, providing a secure and serviceable connection for industrial power cables.
