Ilme TM3243KSSP is a compact 32 A 3-pole 2P+E IP66/IP67 interlocked switched industrial socket-outlet for 100–130 V AC supplies, including nominal 110 V applications, supplied without a backbox.
£86.86
The Ilme TM3243KSSP is a compact 32 A interlocked switched industrial socket-outlet designed for safe and reliable low-voltage power distribution in demanding industrial environments. Part of the Ilme TM series, this model combines a 3-pole 2P+E configuration with a mechanically interlocked switch and is supplied without a backbox for integration into compatible Ilme single or multiple enclosure systems.
Designed for 100–130 V AC at 50/60 Hz applications, including nominal 110 V industrial supplies, the TM3243KSSP uses the standard yellow IEC industrial socket identification and a 4 h earth contact position. Its double mechanical interlock prevents the switch from being turned on unless the plug is inserted and prevents withdrawal of the plug while the switch is in the ON position, improving safety during industrial operation.
The TM3243KSSP features an enclosure manufactured from self-extinguishing insulating thermoplastic and offers an IP66/IP67 degree of protection when correctly installed with an appropriate enclosure and cable-entry arrangement. With IK10 impact resistance up to 20 J, a bayonet-jointed lid and a switch handle that can be padlocked in both the O and I positions, it is well suited to factories, workshops, construction equipment and industrial power distribution systems.
Interlocked switched socket-outlets provide an additional level of operational safety by coordinating electrical switching with plug connection and disconnection. The Ilme TM3243KSSP incorporates a double mechanical interlock that prevents the switch from being moved to the ON position when a compatible plug is not inserted and prevents the plug from being withdrawn while the switch remains ON.
As a compact 32K model supplied without a backbox, the TM3243KSSP is designed to be installed into a compatible Ilme single or multiple box. This modular arrangement makes it particularly useful when constructing industrial distribution assemblies containing multiple socket-outlets while retaining the robust protection and switching functionality of the Ilme TM system.
| Manufacturer | Ilme |
|---|---|
| Series | TM |
| Model | TM3243KSSP |
| Alternative part number | TM 3243KSSP |
| Product type | Interlocked switched industrial socket-outlet without backbox |
| Rated current | 32 A |
| Nominal application voltage | 110 V AC |
| Rated voltage range | 100–130 V AC |
| Frequency | 50 / 60 Hz |
| Number of poles | 3 pole, 2P+E |
| Earth contact position | 4 h |
| Protection rating | IP66/IP67 when correctly installed |
| Impact resistance | IK10 / 20 J |
| Enclosure material | Self-extinguishing insulating thermoplastic |
| Enclosure colour | RAL 7012 grey |
| Socket colour | Yellow |
| Format | Compact 32K |
| Backbox | Not included |
| Switch | Mechanically interlocked |
| Standards | EN 60309-1, EN 60309-2 and EN 60309-4 |
| Barcode | 8015747126472 |
The TM3243KSSP is a 32 A interlocked switched industrial socket-outlet designed for low-voltage power distribution, including nominal 110 V industrial supplies in factories, workshops, machinery and distribution systems.
The TM3243KSSP is rated at 32 A and is designed for 100–130 V AC at 50/60 Hz, making it suitable for nominal 110 V industrial applications.
The TM3243KSSP is a 3-pole 2P+E socket-outlet, providing two power contacts plus protective earth, with the earth contact positioned at 4 h.
No. The TM3243KSSP is supplied without a backbox and is intended to be mounted into a compatible Ilme single or multiple enclosure as part of a complete TM industrial distribution system.
The socket-outlet is designed for an IP66/IP67 degree of protection when correctly installed with a suitable Ilme enclosure and cable-entry arrangement. It also provides IK10 impact resistance up to 20 J.
Ilme TM interlocked switched socket-outlets combine robust industrial construction with mechanical interlocking and high ingress protection, providing dependable power connections for demanding low-voltage industrial distribution systems.
