WAGO 750-617 is a 24 V AC field power supply module with a 5 × 20 mm fuse holder and 6.3 A power jumper contact capacity for WAGO I/O System 750/753 industrial automation stations.
£51.22
The WAGO 750-617 is a compact and reliable 24 V AC field power supply module with fuse holder designed for the WAGO I/O System 750/753. It introduces the required 24 V AC field supply into a modular I/O station and distributes the protected supply potential to compatible downstream modules through integrated power jumper contacts.
Designed for industrial automation and distributed I/O applications, the 750-617 incorporates an accessible fuse holder for a 5 × 20 mm time-delay fuse rated up to 6.3 A. The replaceable fuse provides convenient protection for the field supply circuit, while red and green LED indicators provide clear visual information about fuse condition and power supply status.
With a 24 V AC field supply and power jumper contacts capable of carrying up to 6.3 A, the WAGO 750-617 is ideal for establishing or refreshing a protected 24 V AC potential group within modular industrial I/O stations. Its slim 12 mm-wide design, DIN rail mounting and WAGO CAGE CLAMP® connections simplify integration into industrial control cabinets.
Industrial I/O stations often require dedicated field-side supply potentials for sensors, actuators and other connected devices. The WAGO 750-617 introduces a protected 24 V AC field supply into the I/O node and transfers this potential to compatible downstream modules through its integrated power jumper contacts.
The accessible fuse holder allows the field supply to be protected locally and simplifies maintenance when a fuse needs to be replaced. Visual LED indication helps engineers quickly confirm supply status or identify a defective fuse, supporting efficient troubleshooting and dependable operation in industrial automation systems.
| HS Code | 85389091 |
|---|---|
| Country of Manufacture | Germany |
| Manufacturer | WAGO |
| Series | WAGO I/O System 750/753 |
| Model | 750-617 |
| Product type | Field power supply module with fuse holder |
| Signal type | Voltage |
| Signal voltage | 24 V AC |
| Field supply voltage | 24 V AC |
| System supply voltage | 5 V DC via data contacts |
| Current-carrying capacity of power jumper contacts | 6.3 A |
| Fuse | 5 × 20 mm, T 6.3 A |
| Fuse supplied | No |
| Outgoing power jumper contacts | 3 |
| Indicators | Red LED for defective fuse; green LED for power supply status |
| Connection technology | CAGE CLAMP® |
| Field supply connections | 6 × CAGE CLAMP® |
| Conductor cross-section | 0.08–2.5 mm² |
| Conductor size | AWG 28–14 |
| Strip length | 8–9 mm |
| Protection rating | IP20 |
| Mounting type | DIN 35 rail mounting |
| Operating temperature | 0–55 °C |
| Storage temperature | -25 °C to +85 °C |
| Width | 12 mm |
| Weight | approx. 50 g |
The WAGO 750-617 is used to introduce a protected 24 V AC field supply into a WAGO I/O System 750/753 station and distribute that supply to compatible downstream I/O modules.
The module is designed for a 24 V AC field supply.
The module accepts a 5 × 20 mm time-delay fuse rated up to 6.3 A. The fuse is installed in an accessible fuse holder and is not included with the module.
Yes. A red LED indicates a defective fuse, while a green LED provides visual indication of the field power supply status.
The power jumper contacts have a maximum current-carrying capacity of 6.3 A.
WAGO I/O System 750/753 supply modules provide dependable field-side power distribution for modular industrial automation systems, combining compact DIN rail installation with reliable spring connection technology and practical circuit protection.
