Why Choose the ABB 831100 ARIA 86 Pertinax Mounting Plate?
The ABB 831100 ARIA 86 Pertinax Mounting Plate is a purpose-designed internal mounting accessory for compatible ABB ARIA 86 electrical enclosures. Measuring 550 mm wide × 750 mm high × 5 mm thick, this solid mounting panel provides a substantial surface for installing suitable electrical distribution, control and switching components. Manufactured from Pertinax insulating hard-paper laminate, it offers a non-metallic alternative to conventional steel mounting plates.
Part of the ABB ARIA Enclosures product range, the mounting plate is identified by manufacturer type AR086I03 and ABB order code 4TBA831100C0100. Its 5 mm insulating laminate construction makes it particularly useful where an electrically insulating mounting substrate is preferred. The plate features an untreated surface and a solid, non-perforated design, allowing suitably qualified installers to plan component positions according to the requirements of the electrical assembly.
Designed specifically for the ABB ARIA 86 enclosure format, the 831100 provides a coordinated mounting solution for professional panel builders, electrical contractors and maintenance engineers. Its generous dimensions accommodate a variety of suitable equipment layouts, while the Pertinax material helps avoid the use of an exposed metallic mounting surface. Whether specified for a new electrical installation, an enclosure refurbishment or a replacement mounting panel, the ABB AR086I03 offers a practical accessory for compatible ARIA 86 cabinets.
Key Advantages
- Purpose-designed for ABB ARIA 86 enclosures, supporting accurate accessory selection and installation.
- 550 × 750 mm mounting surface provides substantial space for electrical equipment layouts.
- 5 mm Pertinax construction offers a rigid, electrically insulating mounting substrate.
- Non-metallic mounting surface provides an alternative to galvanised steel mounting plates.
- Solid, non-perforated design allows suitable mounting positions to be established during panel assembly.
- Insulating hard-paper laminate is suitable for applications requiring a non-conductive equipment mounting panel.
- Dedicated ARIA 86 compatibility supports coordinated enclosure and accessory selection.
- Generous vertical mounting space helps accommodate organised component arrangements.
- Untreated surface finish retains the material's standard manufacturer-supplied condition.
- Manufacturer-specific product reference simplifies replacement and procurement.
- Suitable for new panel assemblies and refurbishment of compatible electrical cabinets.
- Single-piece mounting panel provides a continuous substrate for appropriately mounted equipment.
- Part of the established ABB ARIA universal polyester enclosure accessory range.
Key Features
- ABB ARIA 86 Pertinax mounting plate.
- Product reference: 831100.
- ABB extended product type: AR086I03.
- ABB order code: 4TBA831100C0100.
- Compatible enclosure series: ABB ARIA 86.
- Mounting plate material: Pertinax.
- Material description: Insulating hard-paper laminate.
- Surface finish: Untreated.
- Mounting plate width: 550 mm.
- Mounting plate height: 750 mm.
- Mounting plate thickness: 5 mm.
- Plate configuration: Solid, non-perforated.
- Product net weight: 3 kg.
- Accessory type: Internal electrical equipment mounting plate.
- Installation location: Inside a compatible ABB ARIA 86 enclosure.
- Product supply: One mounting plate.
- Application: Mounting suitable electrical distribution and control components.
Understanding Pertinax Mounting Plates for Electrical Enclosures
The ABB 831100 AR086I03 is manufactured from Pertinax, an insulating laminate commonly associated with resin-bonded paper materials. Unlike a conventional metal mounting plate, Pertinax provides a non-metallic substrate for supporting suitable electrical components. This makes it useful for enclosure configurations where the mounting surface itself is intended to be electrically insulating. The plate's 5 mm thickness and large 550 × 750 mm format provide a practical foundation for equipment layouts within the ARIA 86 enclosure system.
The mounting plate is supplied with an untreated surface and a non-perforated construction. A solid plate allows installers to determine suitable component positions and mounting arrangements for the particular electrical assembly. However, drilling, cutting or otherwise modifying the panel should be undertaken only where permitted by the relevant installation instructions. Fixing methods must be appropriate for the Pertinax material and the weight of the installed equipment. Care should also be taken to prevent cracking, delamination or damage during machining and installation.
Although Pertinax is an insulating material, the ABB 831100 mounting plate does not independently establish the insulation class, voltage rating or ingress protection of a completed electrical assembly. Those characteristics depend on the enclosure, installed devices, wiring arrangements, clearances and applicable design requirements. The plate is intended for compatible ABB ARIA 86 enclosures and should be selected alongside suitable enclosure accessories. Installers must verify mechanical support, electrical clearances, thermal performance and any protective bonding requirements before the completed installation is placed into service.
Typical Applications
- Internal equipment mounting within ABB ARIA 86 electrical enclosures.
- Electrical control panels requiring a non-metallic mounting substrate.
- Industrial electrical distribution cabinet assemblies.
- Mounting suitable switching and control components.
- Electrical installations where an insulating mounting panel is preferred.
- Commercial building services control equipment.
- Industrial automation and process control assemblies.
- Custom electrical panel layouts using compatible ABB ARIA accessories.
- Electrical enclosure refurbishment and maintenance projects.
- Replacement of existing ABB ARIA 86 Pertinax mounting plates.
- Mounting suitable terminal assemblies and associated electrical equipment.
- Professional electrical panel-building applications.
