Lovato YD11230 star-delta motor starter rated for 11 kW three-phase motors with 22 A AC3 current rating and 230 V AC control voltage for reduced-current motor starting.
£314.86
The Lovato YD11230 is a reliable star-delta motor starter designed to reduce motor starting current while providing dependable starting and stopping of three-phase induction motors. As part of the proven Lovato L-Starter range, this enclosed starter is ideal for industrial applications where reduced inrush current is required for larger motors.
Featuring integrated Start and Stop push-button controls, the YD11230 automatically transitions from star to delta operation after the preset starting period, reducing electrical stress on the power supply and mechanical stress on the motor. The durable IP65 insulated enclosure protects the internal components from dust and water ingress, making it suitable for demanding industrial environments.
With a rated motor power of 11 kW, a 22 A operational current and a 230 V AC control coil, the YD11230 is well suited to compressors, pumps, conveyors and other machinery requiring reduced-current motor starting. A compatible thermal overload relay is selected separately and should be set to approximately 58% of the motor full-load current for star-delta applications.
Star-delta starters reduce motor starting current by initially connecting the motor windings in a star configuration before automatically switching to delta for normal operation. This reduces electrical and mechanical stress while providing a cost-effective solution for starting larger three-phase motors.
The Lovato YD11230 is widely used by panel builders, OEM manufacturers and industrial maintenance engineers requiring dependable reduced-current motor starting for fixed-speed industrial equipment.
Tick the specs you need, then view products that match.
| With Isolator | No | |
|---|---|---|
| Starter Type | Star Delta | |
| Voltage | 400 V | |
| Power | 11 kW | |
| Current | 22 A | |
| Phase | Three Phase | |
| IP Rating | IP65 | |
| Coil / Supply Voltage | 230 V AC | |
| Series | L-Starter YD Series | |
| Product type | Star-delta motor starter | |
| Rated motor power | 11 kW | |
| Horsepower rating | 15 HP | |
| Maximum AC3 current | 22 A | |
| Control voltage | 230 V AC | |
| Input phases | 3-phase | |
| Protection rating | IP65 enclosure | |
| Enclosure material | Insulated polycarbonate | |
| Mounting type | Surface mounting | |
| Dimensions (H × W × D) | approx. 220 × 280 × 170 mm | |
| Overload relay compatibility | RF38 series | |
| Compliance | IEC/EN 60947-1, IEC/EN 60947-4-1 |
It is used to provide reduced-current starting for three-phase induction motors before automatically switching to normal delta operation.
The YD11230 is designed for motors rated up to 11 kW.
This model is fitted with a 230 V AC control coil.
No. A compatible thermal overload relay must be selected separately and set according to the motor full-load current for star-delta operation.
Star-delta starters reduce motor starting current and minimise mechanical stress, making them ideal for larger motors where reduced inrush current is required.
Lovato L-Starter star-delta starters are trusted by OEM manufacturers, control panel builders and industrial engineers for reliable reduced-current motor starting, robust construction and dependable long-term performance.
