Lovato 51ADXTAST is a 96 × 96 mm remote keypad for compatible 51ADX soft starters with a 2-line 16-character backlit LCD, 208–240 V AC supply, RS485 communication and an included 3 m 51C8 connecting cable.
£329.33
The Lovato 51ADXTAST is a dedicated remote keypad for Lovato 51ADX soft starters, designed to provide convenient panel-mounted access to soft starter configuration, measurements and operating information. Its 96 × 96 mm flush-mount format and 2-line, 16-character backlit LCD make it suitable for machine control panels and industrial switchboards where the soft starter itself is installed away from the operator interface.
The remote keypad provides functionality comparable with the keypad integrated into compatible 51ADX soft starters, while motor start and stop commands are permanently disabled on the remote unit. Operators can configure the soft starter, read measurements and operating data, and transfer parameter settings between the 51ADX soft starter and the keypad, allowing a backup copy of configuration data to be retained.
The 51ADXTAST operates from a 208–240 V AC, 50/60 Hz auxiliary supply and communicates with the soft starter through an RS485 interface. It is supplied complete with a 51C8 3 m / 10 ft connecting cable for connection to the RS485 port of a compatible Lovato 51ADX soft starter.
The Lovato 51ADXTAST allows important configuration and monitoring functions of a compatible 51ADX soft starter to be brought to the front of an electrical enclosure. This is particularly useful when the soft starter is mounted inside a cabinet and routine access to parameters, measurements and operating information is required without opening the panel.
Parameter transfer functions allow settings to be copied between the 51ADX and the remote keypad, providing a convenient method of retaining and transferring configuration data. The backlit LCD, status LEDs and six-key interface provide straightforward navigation, while the supplied 51C8 cable enables direct connection to the soft starter's RS485 interface.
Tick the specs you need, then view products that match.
| Motor Protection | Yes | |
|---|---|---|
| Phase | Three Phase | |
| HS Code | 85371098 | |
| Manufacturer | Lovato Electric | |
| Family | Soft Starters | |
| Model | 51ADXTAST | |
| Product type | Remote keypad | |
| Compatible series | Lovato 51ADX soft starters | |
| Display | 2-line, 16-character backlit LCD | |
| Front dimensions | 96 × 96 mm | |
| Auxiliary supply voltage | 208–240 V AC ±10% | |
| Supply frequency | 50 / 60 Hz | |
| Power consumption | 6.9 VA | |
| Power dissipation | 3.2 W | |
| Communication interface | RS485 | |
| RS485 connection | RJ4/4 connector | |
| Supply connection | Removable 3-pole terminal block | |
| Status indicators | POWER, RUN and FAULT LEDs | |
| Operator keys | 6 | |
| Mounting type | Flush / panel mounting | |
| Front protection rating | IP41 | |
| Operating temperature | −10 to +60 °C | |
| Storage temperature | −20 to +70 °C | |
| Included cable | Lovato 51C8 | |
| Cable length | 3 m / 10 ft | |
| Product weight | 480 g | |
| Package dimensions | 139 × 105 × 103 mm | |
| EAN | 8013975066256 |
The 51ADXTAST is a remote panel-mounted keypad for compatible Lovato 51ADX soft starters, allowing users to configure parameters and view measurements and operating information away from the starter itself.
The keypad features a 2-line, 16-character backlit LCD together with POWER, RUN and FAULT status LEDs.
The remote keypad requires a 208–240 V AC ±10%, 50/60 Hz auxiliary supply.
Yes. The 51ADXTAST is supplied with a Lovato 51C8 3 m / 10 ft connecting cable for connection to the RS485 port of a compatible 51ADX soft starter.
Yes. Parameters can be transferred between the 51ADX soft starter and the remote keypad, allowing configuration data to be backed up and subsequently transferred when required.
