Lovato P1MS1P100 is a single-pole 100 A modular switch disconnector with 230–240 V AC operational voltage, 1000 V insulation rating and compact one-module DIN rail mounting for dependable electrical circuit isolation.
£25.04
The Lovato P1MS1P100 is a compact and dependable single-pole modular switch disconnector designed for the disconnection and isolation of electrical power lines and systems. As part of the Lovato P1MS modular switch disconnector series, it provides a practical solution for electrical distribution boards, industrial control panels and machinery where reliable manual circuit isolation is required.
Rated at 100 A, the P1MS1P100 is also suitable for switching appropriately rated resistive and inductive loads. Clear contact status indication helps operators identify the switching state, while wide terminals support straightforward wiring. Optional auxiliary contact and padlockable accessories provide additional flexibility for signalling and isolation applications.
With a rated operational voltage of 230–240 V AC, a rated insulation voltage of 1000 V and a compact one-module design, the P1MS1P100 delivers high current capability while minimising panel space. Standard 35 mm DIN rail mounting makes installation straightforward in professional modular distribution and control equipment.
Switch disconnectors such as the Lovato P1MS1P100 provide a defined means of manually disconnecting and isolating electrical circuits. This allows sections of an electrical installation to be separated from the supply during operation, inspection or maintenance when the device is correctly selected and installed within the system.
The P1MS series combines compact DIN rail construction with clear contact indication and practical wiring features. The P1MS1P100 provides a 100 A single-pole switching solution in only one DIN module, making it particularly useful for higher-current applications where panel space is limited.
Tick the specs you need, then view products that match.
| Device Type | Modular Switch Disconnect | |
|---|---|---|
| Mounting Type | DIN rail | |
| Current | 100 A | |
| Poles | 1-pole | |
| Manufacturer | Lovato Electric | |
| Series | P1MS Modular Switch Disconnectors | |
| Model | P1MS1P100 | |
| Product type | Modular switch disconnector | |
| Number of poles | 1P | |
| Number of DIN modules | 1 | |
| Rated current In | 100 A | |
| Rated operational voltage AC | 230–240 V AC | |
| Rated frequency | 50/60 Hz | |
| Rated insulation voltage Ui | 1000 V | |
| Rated impulse withstand voltage Uimp | 4 kV | |
| Short-circuit rating | 25 kA with 63 A gG fuse; 15 kA with 125 A gG fuse | |
| Electrical life | 1000 cycles | |
| Mechanical life | 7000 cycles | |
| Operating temperature | -25 to +70 °C | |
| Storage temperature | -25 to +70 °C | |
| Maximum altitude | 2000 m | |
| Mounting | 35 mm DIN rail | |
| Normal operating position | Vertical plane | |
| Terminal tightening torque | 3.2–3.5 Nm | |
| Terminal tool | Pz2 | |
| Conductor section | 1–50 mm² | |
| Pollution degree | 3 | |
| Weight | approx. 83 g | |
| Compliance | IEC | |
| EAN13 | 8013975267264 | |
| HS code | 85369095 |
The P1MS1P100 is a single-pole modular switch disconnector used primarily for the disconnection and isolation of electrical power lines and systems, and it can also switch appropriately rated resistive and inductive loads.
The Lovato P1MS1P100 has a rated current of 100 A.
The P1MS1P100 has a rated operational voltage of 230–240 V AC and a rated insulation voltage of 1000 V.
The P1MS1P100 occupies one DIN module and mounts onto a standard 35 mm DIN rail inside a suitable electrical panel or distribution enclosure.
The P1MS1P100 accepts IEC conductor sizes from 1–50 mm² through its wide terminals.
Lovato Electric P1MS modular switch disconnectors are used by electrical engineers, panel builders and OEM manufacturers for compact and dependable circuit isolation in industrial and commercial electrical systems.
