WAGO 2004-402 is a light grey 2-way insulated TOPJOB S push-in jumper bar rated at 32 A for commoning adjacent compatible 2004 Series terminal blocks.
£0.21
The WAGO 2004-402 is a compact and reliable 2-way insulated push-in type jumper bar designed for commoning compatible WAGO TOPJOB® S 2004 Series rail-mounted terminal blocks. Finished in light grey, it provides a convenient method of electrically connecting adjacent terminal blocks to distribute a common potential across two terminal positions.
As part of the WAGO TOPJOB® S 2004 Series accessory range, the 2004-402 uses WAGO's push-in jumper system for fast installation into the dedicated jumper slots of compatible terminal blocks. The jumper contacts are manufactured from electrolytic copper, while the terminal block's spring-loaded jumper interface provides a secure connection suitable for industrial control, power distribution and automation applications.
The WAGO 2004-402 is a 2-way jumper rated at 32 A with a nominal voltage rating of 800 V. Measuring approximately 10.3 × 4.1 × 19 mm, its compact insulated design allows efficient potential distribution without requiring additional wiring between adjacent terminals.
Push-in jumper bars provide an efficient alternative to installing separate conductors between terminal blocks that require the same electrical potential. By plugging directly into dedicated jumper slots, the WAGO 2004-402 creates a common electrical connection between two adjacent compatible terminal positions while helping reduce wiring time and panel complexity.
The TOPJOB® S jumper system uses conductive copper contacts and spring-loaded interfaces to provide compact and dependable commoning. This makes the 2004-402 particularly useful for distributing supply potentials, control voltages and other common electrical connections throughout industrial terminal block assemblies.
Tick the specs you need, then view products that match.
| Product Series | WAGO TOPJOB S | |
|---|---|---|
| Terminal Type | Jumper / Cross-connector (accessory) | |
| Colour | Grey | |
| HS Code | 85366990 | |
| Country of Manufacture | Germany | |
| Manufacturer | WAGO | |
| Series | TOPJOB® S 2004 | |
| Model | 2004-402 | |
| Manufacturer part number | 2004-402 | |
| Product type | Push-in type jumper bar | |
| Terminal type | Jumper bar | |
| Number of ways | 2 | |
| Jumper assignment | 1–2 | |
| Terminal size | 4 mm² | |
| Connection type | Push-in jumper connection | |
| Rated current | 32 A | |
| Nominal voltage | 800 V | |
| Rated current (Ex e II) | 30 A | |
| Colour | Light grey | |
| Insulation material | Polyamide (PA66) | |
| Material group | I | |
| Flammability class | UL 94 V0 | |
| Width | 10.3 mm | |
| Height | 4.1 mm | |
| Depth | 19 mm | |
| Weight | approx. 1.4 g | |
| Fire load | 0.007 MJ | |
| Processing temperature | -35 to +85 °C | |
| Continuous operating temperature | -60 to +105 °C | |
| Packaging quantity | 25 pieces | |
| Barcode | 4055143700153 |
The WAGO 2004-402 is a 2-way push-in jumper bar used to electrically common two adjacent compatible TOPJOB® S 2004 Series terminal positions.
The WAGO 2004-402 has a rated current of 32 A for standard applications.
The jumper is a 2-way design with a 1–2 jumper assignment, allowing two adjacent compatible terminal positions to be electrically connected.
The WAGO 2004-402 is light grey and features an insulated housing manufactured from PA66 polyamide.
The jumper uses WAGO's push-in type jumper system and plugs into the dedicated jumper slots of compatible TOPJOB® S terminal blocks, eliminating the need for separate jumper wiring between the two positions.
WAGO TOPJOB® S push-in jumper bars provide panel builders and electrical engineers with a fast, compact and dependable method of commoning terminal blocks for industrial automation, machinery and low-voltage electrical installations.
