WAGO 2004-403 is a light grey 3-way insulated TOPJOB S push-in jumper bar rated at 32 A and 800 V for commoning three adjacent compatible terminal block positions.
£0.4355
The WAGO 2004-403 is a compact and reliable 3-way insulated push-in type jumper bar designed for commoning compatible WAGO TOPJOB® S rail-mounted terminal blocks. Finished in light grey, it provides an efficient way to electrically connect three adjacent terminal positions and distribute a common potential without installing separate jumper wires.
As part of the WAGO TOPJOB® S jumper system, the 2004-403 plugs directly into the dedicated jumper slots of compatible terminal blocks. This push-in arrangement simplifies panel wiring and allows common potentials to be distributed quickly across terminal groups, making it particularly useful in industrial control cabinets, machinery and automation systems.
The WAGO 2004-403 has a rated current of 32 A and a nominal voltage of 800 V. Designed for 4 mm² terminal applications, the three-way jumper measures approximately 16.5 × 4.1 × 19 mm and combines conductive jumper contacts with durable PA66 polyamide insulation for dependable operation in professional electrical installations.
Push-in jumper bars provide an efficient alternative to individual wiring when several terminal blocks need to share the same electrical potential. By plugging directly into dedicated jumper slots, the WAGO 2004-403 electrically connects three compatible terminal positions while reducing wiring effort and helping maintain a compact, organised terminal strip.
The TOPJOB® S jumper system is particularly useful for distributing supply voltages, control potentials and other common electrical connections within industrial panels. The three-way configuration of the 2004-403 makes it suitable wherever a common potential needs to be distributed across three adjacent compatible terminal blocks.
Tick the specs you need, then view products that match.
| Product Series | WAGO TOPJOB S | |
|---|---|---|
| Terminal Type | Jumper / Cross-connector (accessory) | |
| Colour | Grey | |
| HS Code | 85366990 | |
| Country of Manufacture | Germany | |
| Manufacturer | WAGO | |
| Series | TOPJOB® S | |
| Model | 2004-403 | |
| Manufacturer part number | 2004-403 | |
| Product type | Push-in type jumper bar | |
| Terminal type | Jumper bar | |
| Number of ways | 3 | |
| Jumper assignment | 1–2–3 | |
| Terminal size | 4 mm² | |
| Connection type | Push-in jumper connection | |
| Rated current | 32 A | |
| Nominal voltage | 800 V | |
| Rated current (Ex e II) | 30 A | |
| Colour | Light grey | |
| Insulation material | Polyamide (PA66) | |
| Material group | I | |
| Flammability class | UL 94 V0 | |
| Width | 16.5 mm | |
| Height | 4.1 mm | |
| Depth | 19 mm | |
| Weight | approx. 2.2 g | |
| Fire load | 0.011 MJ | |
| Processing temperature | -35 to +85 °C | |
| Continuous operating temperature | -60 to +105 °C | |
| Packaging quantity | 25 pieces | |
| GTIN | 4055143699761 |
The WAGO 2004-403 is a 3-way push-in jumper bar used to electrically common three adjacent compatible TOPJOB® S terminal positions.
The WAGO 2004-403 has a rated current of 32 A for standard applications and a rated current of 30 A for Ex e II applications.
The jumper has a 3-way configuration with a 1–2–3 jumper assignment, allowing three adjacent compatible terminal positions to share a common electrical potential.
The jumper measures approximately 16.5 mm wide, 4.1 mm high and 19 mm deep.
The jumper uses WAGO's push-in type jumper system and plugs directly into the dedicated jumper slots of compatible TOPJOB® S terminal blocks, eliminating the need for separate jumper wiring between the three positions.
WAGO TOPJOB® S push-in jumper bars provide panel builders and electrical engineers with a fast, compact and dependable method of commoning terminal blocks for industrial automation, machinery and low-voltage electrical installations.
