WAGO 2004-404 TOPJOB S light-grey 4-way insulated push-in jumper bar with 6.2 mm modular spacing, 32 A rated current and 800 V rated voltage for common-potential distribution across compatible 4 mm²-class terminal blocks.
£0.624
The WAGO 2004-404 is an insulated 4-way push-in jumper bar designed for reliable common-potential distribution across compatible WAGO TOPJOB® S rail-mounted terminal blocks. Developed for the WAGO 2004 Series, this light-grey transverse connector provides a compact and efficient alternative to individual wire links in industrial control panels, machinery and electrical distribution systems.
The 2004-404 plugs directly into the jumper slots of compatible terminal blocks, electrically bridging four adjacent positions. Its insulated construction provides shock protection while maintaining an organised terminal-strip layout, and the pluggable design enables quick installation during panel assembly, modification and maintenance.
Featuring 4-way bridging, a 6.2 mm modular spacing and a rated current of 32 A, the WAGO 2004-404 is designed for compatible 4 mm²-class terminal block systems. With an 800 V rated voltage and suitability for Ex e configurations where permitted by the applicable terminal approvals, it provides dependable potential distribution for demanding industrial installations.
Terminal block jumper bars allow one electrical potential to be distributed across several adjacent terminals without installing separate conductor links. The WAGO 2004-404 bridges four compatible positions simultaneously, reducing wiring requirements and helping create a cleaner, more space-efficient terminal assembly.
Its pluggable design works with the integrated jumper system of compatible WAGO TOPJOB® S terminal blocks, allowing panel builders to establish common potentials quickly while retaining convenient access to conductor connection, testing and marking facilities. The insulated body also helps protect the conductive jumper elements within the assembled terminal strip.
Tick the specs you need, then view products that match.
| Product Series | WAGO TOPJOB S | |
|---|---|---|
| Terminal Type | Jumper / Cross-connector (accessory) | |
| Colour | Grey | |
| HS Code | 85366990 | |
| Country of Manufacture | Germany | |
| Manufacturer | WAGO | |
| Series | TOPJOB® S 2004 Series | |
| Model | 2004-404 | |
| Product type | Insulated push-in jumper bar | |
| Terminal accessory type | Jumper bar / transverse connector | |
| Number of ways | 4 | |
| Number of bridged positions | 4 | |
| Terminal size | 4 mm² | |
| Modular spacing | 6.2 mm | |
| Mounting method | Pluggable / push-in | |
| Rated current | 32 A | |
| Rated voltage | 800 V | |
| Insulated | Yes | |
| Shock protection | Yes | |
| Colour | Light grey | |
| Width | 22.8 mm | |
| Height | 4.1 mm | |
| Depth | 19 mm | |
| Weight | approx. 3.06 g | |
| Pack quantity | 25 pieces | |
| GTIN / EAN | 4055143699846 | |
| Country of origin | Germany |
The WAGO 2004-404 is used to electrically bridge four compatible adjacent terminal positions, distributing a common potential without requiring individual wire links between the terminals.
The 2004-404 is a 4-way jumper bar designed to bridge four compatible terminal positions.
The WAGO 2004-404 has a rated current of 32 A when used within an appropriately rated compatible terminal assembly.
The jumper has a 6.2 mm modular spacing for use with compatible WAGO TOPJOB® S terminal blocks.
Yes. The 2004-404 is an insulated light-grey jumper bar designed to provide protected and organised cross-connection between compatible terminal positions.
WAGO TOPJOB® S jumper bars are widely used by panel builders and automation engineers to create compact and dependable common-potential connections across compatible DIN-rail terminal blocks while reducing additional wiring and installation effort.
