IMO XBL-CSEA XGB CANopen slave communication module with one CANopen port, 64 TPDOs, 64 RPDOs and transmission speeds from 10 kbps to 1,000 kbps for industrial automation networks.
£374.36
The IMO XBL-CSEA is an industrial CANopen slave communication module designed for compatible XGB programmable logic controller (PLC) systems. It enables an XGB PLC to operate as a CANopen slave device, providing reliable data exchange with a CANopen master in machinery, process control and factory automation applications.
Designed in accordance with the established CANopen communication standard, the XBL-CSEA supports transmission rates from 10 kbps to 1,000 kbps and provides one CANopen communication port. It supports PDO and SDO communication, SYNC consumer functionality, NMT slave operation and Heartbeat error control, providing the essential services required for integration into industrial CANopen networks.
The module supports up to 64 TPDOs and 64 RPDOs, with a maximum data length of 8 bytes per PDO. Its compact 90 × 27 × 60 mm dimensions make it suitable for space-conscious industrial control panels, while diagnostic functionality can store up to the latest 10 error events to assist with system commissioning and troubleshooting.
CANopen is an industrial communication protocol based on the CAN bus and is widely used for connecting PLCs, drives, motion equipment, sensors, actuators and distributed control devices. The IMO XBL-CSEA allows a compatible XGB PLC system to participate in such a network as a CANopen slave, exchanging process and configuration data with the controlling CANopen master.
The XBL-CSEA supports Process Data Objects (PDOs) for efficient process-data exchange and Service Data Objects (SDOs) for configuration and parameter communication. Combined with SYNC consumer, NMT slave and Heartbeat functionality, this provides a versatile communication platform for integrating XGB controllers into established CANopen automation architectures.
| Manufacturer | IMO |
|---|---|
| Series | XGB |
| Model | XBL-CSEA |
| Product type | CANopen slave communication module |
| Communication protocol | CANopen |
| Network function | CANopen Slave |
| CANopen specification | CiA DS 301 |
| Number of communication ports | 1 |
| Transmission speeds | 10, 20, 50, 100, 125, 250, 500, 800, 1,000 kbps |
| Supported TPDOs | 64 |
| Supported RPDOs | 64 |
| Maximum data length per PDO | 8 bytes |
| PDO transmission types | Synchronous acyclic, synchronous cyclic, RTR, time-event trigger |
| Supported SDOs | 1 server |
| SDO transmission | Expedited and normal |
| Network access method | CSMA/BA |
| Network topology | Bus |
| SYNC service | Consumer |
| NMT node control | NMT Slave |
| NMT error control | Heartbeat |
| Error history | Up to 10 latest events |
| Communication connector | 5-pin open-type CAN connector |
| Current consumption | 202 mA |
| Dimensions (H × W × D) | 90 × 27 × 60 mm |
| Weight | 102 g |
| HS Code | 8537109199 |
| Country of Manufacture | South Korea |
The XBL-CSEA is a CANopen slave communication module that allows a compatible XGB PLC system to communicate as a slave device on an industrial CANopen network.
The module supports CANopen transmission rates of 10, 20, 50, 100, 125, 250, 500, 800 and 1,000 kbps.
The XBL-CSEA operates as a CANopen slave. For applications requiring an XGB CANopen master module, the corresponding module is the XBL-CMEA.
The XBL-CSEA supports up to 64 TPDOs and 64 RPDOs, with a maximum data length of 8 bytes per PDO.
The XBL-CSEA measures 90 × 27 × 60 mm (H × W × D), providing a compact CANopen communication solution for compatible XGB PLC installations.
IMO XGB communication modules provide machine builders, system integrators and automation engineers with flexible industrial networking options for integrating PLC control systems into CANopen-based machinery and distributed automation equipment.
