Why Choose the WAGO 2001-410 TOPJOB S 10-Way Jumper Bar?
The WAGO 2001-410 is a 10-way insulated push-in type jumper bar designed for electrically commoning compatible WAGO TOPJOB S 2001 Series rail-mounted terminal blocks. Developed for the 1.5 mm² terminal block range, it provides a fast and reliable method of distributing electrical potential across multiple adjacent terminals without installing individual bridging wires.
The jumper uses WAGO's push-in jumper system, allowing it to plug directly into the dedicated jumper slots of compatible terminal blocks. Its conductive contacts are manufactured from electrolytic copper for efficient current transfer, while the insulated light-grey housing provides protection and clear integration within organised terminal assemblies.
With a rated current of 18 A and nominal voltage of 800 V according to IEC/EN ratings, the WAGO 2001-410 is suitable for industrial control, automation and electrical distribution applications. The jumper provides ten positions at a 4.2 mm pitch and can also be customised by removing individual jumper contacts where fewer commoned positions are required.
Key Advantages
- 10-way push-in jumper bar for efficient commoning of adjacent terminal blocks.
- Designed for WAGO TOPJOB S 2001 Series 1.5 mm² terminal blocks.
- 18 A rated current for reliable circuit distribution.
- 800 V nominal voltage according to IEC/EN ratings.
- Push-in installation eliminates the need for separate bridging wires.
- Individual contacts can be removed to create customised jumper configurations.
Key Features
- WAGO TOPJOB S 2001 Series terminal block accessory.
- 10-way insulated jumper.
- 4.2 mm pitch spacing.
- 18 A rated current.
- 800 V nominal voltage (III/3).
- 16 A rated current for Ex e II applications.
- Light-grey insulated construction.
- High-conductivity electrolytic copper jumper contacts.
- Push-in design for quick installation into compatible jumper slots.
- Removable contacts allow customised commoning arrangements.
Reliable Commoning for TOPJOB S Terminal Blocks
Terminal block jumper bars provide an efficient way to distribute a common electrical potential across several adjacent terminals. Instead of installing and terminating separate bridging conductors, the WAGO push-in jumper system uses dedicated jumper slots and spring-loaded contacts to establish secure electrical connections while maintaining a compact and organised terminal assembly.
The WAGO 2001-410 provides ten commoned positions and can be adapted where required by breaking off individual jumper contacts. This flexibility, combined with its compact dimensions and full-rated current capability, makes it particularly useful for control-panel construction, industrial automation and other applications where multiple terminal connections must share the same electrical potential.
Typical Applications
- Commoning WAGO TOPJOB S 2001 Series terminal blocks.
- Industrial control panels and control cabinets.
- PLC input and output circuit distribution.
- Machine building and factory automation systems.
- Power and signal distribution across DIN rail terminal assemblies.
- Building automation and electrical control installations.
